CHILD SEATS
2
90 - Getting to know your vehicle
2-seater van version: installation table
The table below summarises the information already shown on the previous diagram in order to ensure the regulations
in force are respected.
2-seater van versions
Type of child seat Weight of the child
Front passenger seat(s)
With single passenger seat
With two-seater bench seat
Centre seat Side seat
Shell seat/rear-facing seat
Groups 0, 0+ and 1
< to 13 kg and 9 to 18 kg U (2) X U (2)
Forward-facing seat
Group 1
9 to 18 kg U (1) X U (1)
Booster seat
Groups 2 and 3
15 to 25 kg and 22 to 36 kg U / B2 (1) X U / B2 (1)
X = Seat which does not allow a child seat of this type to be fitted.
U = Seat allowing a child seat with "Universal" approval to be attached by seat belt: check that it can be fitted.
B2 = Seat enabling a child seat with "B2" approval to be attached by seat belt: check that it can be fitted.
(1) To fit a forward-facing child seat, position the back of the child seat so that it is in contact with the vehicle seatback. Raise the
headrest. Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat in the front passenger seat,
check that the Airbag has been deactivated 🡺128.
