TPS-1 User’s Manual: Hardware 4. Shared memory structure
R19UH0081ED0107 Rev. 1.07 page 38 of 86
Jul 30, 2018
4.3. Events from the host to the TPS-1 firmware
Table 4-2: Host Events
Host Event Bits (Host -> Firmware Stack)
APP_EVENT_CONFIG_FINISHED
Set by TPS_StartDevice(). Configuration is valid.
APP_EVENT_APP_RDY_0 Set when the device is complete parameterized for AR0.
Set when the device is complete parameterized for AR1.
APP_EVENT_APP_RDY_2 Set when the device is complete parameterized for AR2 (Supervisor
AR).
Set after processing a request of the Record Mailbox.
APP_EVENT_DIAG_CHANGED Set when the status of the diagnostic mailbox changed.
Is set after the host processes the Framelayout-Parameter out of a
Connect Request of the AR0.
APP_EVENT_ONCONNECT_OK_1 Connect AR1 ok.
Is set after the host processes the Framelayout-Parameter out of a
Connect Request of the AR1.
Is set after the host processes the Framelayout-Parameter out of a
Connect Request of the AR2.
APP_EVENT_ABORT_AR_0 AR0 is disconnected by the host.
AR1 is disconnected by the host.
APP_EVENT_ABORT_AR_2 AR2 is disconnected by the host.
A submodule is pulled out of the device.
APP_EVENT_RETURN_SUBMODULE A submodule returns in to the device.
APP_EVENT_ALARM_SEND_REQ_AR0
Set when an alarm for the AR0 is reported.
APP_EVENT_ALARM_SEND_REQ_AR1 Set when an alarm for the AR1 is reported.
APP_EVENT_ALARM_SEND_REQ_AR2
Set when an alarm for the AR2 is reported.
APP_EVENT_RESET_STACK_CONFIG
A TCP/IP Ethernet frame (MAC) should be send from the mailbox.
APP_EVENT_WRITE_INPUT_DATA Process data written.
APP_EVENT_READ_OUTPUT_DATA
APP_EVENT_RESET_PN_STACK Host CPU forces a software reset of the TPS-1
The application filled the Ethernet mailbox with a record request for the
TPS Communication Interface. The TPS-1 will read the request and
send a response to the application.
