TPS-1 User’s Manual: Hardware Appendix. A Setting of operating modes
R19UH0081ED0107 Rev. 1.07 page 62 of 86
Jul 30, 2018
Host Interface
The host interface realizes the connection of external host CPUs. Data exchange is carried out via an internal Shared Memory area. Depending on the
type of external host CPU, you can choose a serial (SPI slave) or a parallel interface.
Host Parallel Interface
The parallel host interface can be configured to work at 8-bit or 16-bit data width and in Motorola or Intel operating mode. Thus, the interface
facilitates the connection of different processor types.
You find the respective parameters on the window tab “Host Parallel Settings”.
Figure A-2: Parallel host interface configuration
