14
Pneumatic set-up (continued)
Logic table APCA
Pressure Pressure Pressure Pressure
Port 1 0 bar 0 bar
>4.5bar (65.3psi) >4.5bar (65.3psi)
Port 3 0 bar
>4.5bar (65.3psi) 0 bar >4.5bar (65.3psi)
Cover Unknown Extend Retract Extend
“Air bleed” Off Off On On
Logic table APCS
Pressure Pressure
Port 1 0 bar 0 bar
Port 3 0 bar
>4.5bar (65.3psi)
Cover Retract Extend
“Air bleed” N/A N/A
Logic table APCS with “air bleed”
Pressure Pressure Pressure Pressure
Port 1 0 bar 0 bar
>4.5bar (65.3psi) >4.5bar (65.3psi)
Port 3 0 bar
>4.5bar (65.3psi) 0 bar >4.5bar (65.3psi)
Cover Retract Extend Retract Extend
“Air bleed” Off Off On On
