Renishaw APCA Series User Manual

5
Specication
Principle application Tool setting probe with automatic protection cover for lathes and
multi-tasking machines. Contamination management available with “air
bleed”.
Dimensions Length
Width
Depth
189.4mm (7.46 in) extended
45.0 mm (1.77 in)
48.25 mm (1.90 in)
Transmission type Hard-wired transmission
Compatible interfaces HSI or HSI-C
Weight 1200 g (42.33 oz) with 0.5 m (1.64 ft) cable and connector.
Cable
0.5 m (1.6 ft) minimum, M12 connector IEC 61076-2-101. A-standard
male (see note 1).
Sense directions ±X, ±Y, +Z
Unidirectional repeatability 1.50 μm (59 μin) 2σ (see note 2)
Stylus trigger force
(see note 3)
XY plane (low force)
XY plane (high force)
+Z direction
0.49 N, 50.25 gf (1.77 ozf)
0.90 N, 92.21 gf (3.25 ozf)
6.79 N, 692.88 gf (24.44 ozf)
Supply voltage 12 Vdc to 30 Vdc
Supply current HSI 40 mA @ 12 Vdc, 23 mA @ 24 Vdc
HSI-C 110 mA @ 12 Vdc, 80 mA @ 24 Vdc
Pneumatic supply Supply must conform to BS ISO 8573-1: Class 4.6.3. or better.
Maximum operating pressure 6.5 bar (94.27 psi), minimum operating
pressure 4.5 bar (65.27 psi).
Input pneumatic
connections
Three push t ttings for Ø4 mm (0.16 in) tubing (ISO/TS11619:2014)
(see notes 4 and 5).
