31
Service and maintenance (continued)
Cleaning instructions
WARNING: Before working on the APC, ensure
that it is safe to work on and unable to operate.
Remove any swarf build-up on or around APC
daily (as a minimum, it is recommended to clean
out any swarf build-up in the APC once per week).
1. Fully retract APC cover.
2. Unscrew by hand, and remove the APC nose
cone.
3. Clean the inside of the APC and the nose
cone to remove all the residue swarf or other
debris.
Refer to the diagram opposite and use a soft
brush and low pressure coolant jet.
CAUTION: Do not use compressed air, a
sharp tool or a degreasing agent.
4. Fit the nose cone and hand tighten until fully
secure and return to service.
