Renishaw MP10 - Page 11

Optical
centre
line
MP10 70° OUTPUT PROBE + OMI
Probe and OMI diodes must be mutually in
each others field of view, and within the
performance envelope shown.
SWITCH-ON/OFF RANGE
and OPERATING RANGE
The OMP must be within
3 m (9.8 ft) of the OMI.
1-7
PERFORMANCE ENVELOPE
70° OMP
1 (1.33)
3 (9.8)
OMI
60°
45°
60°
45°
15°
30°
30°
15°
2 (6.5)
1 (1.33)
3 (9.8)
45°
90°
60°
15°
75°
30°
2 (6.5)
SWITCH ON/OFF
OPERATING
Range metres (feet)
15°
30°
45°
60°
0°
