USER MANUAL SPREADER X-SERIES
RESQTEC Manual SPREADER X-series (DM064K08)
4.12. ROTATING JAWS
Push/pull the pin towards the green side.
The pin clicks when put in top position.
If applicable: rotate the jaw 180°.
Put the desired jaw back into place on the arms.
Push the pin back into the arms.
The pin clicks when put back into place.
1
2
3
4
