USER MANUAL SPREADER X-SERIES
RESQTEC Manual SPREADER X-series (DM064K08)
5. SPECIFICATIONS
5.1. TECHNICAL SPECIFICATIONS
The spreaders have a series of different capacities at different points of the stroke and different points at the jaws and
protection plates. An overview of forces is given below.
5.1.1 SI-SYSTEM DATA
1
Maximum is a theoretical force that cannot be measured
SPREADER X2
NEO1-COUPLER STD-COUPLER
Nominal pressure 350 bar
Tailhose safety factor - 8:1 (2,800 bar)
Dimensions (L x W x H) 729 x 308 x 267 mm
Operational weight 15.0 kg 16.1 kg
Max. spreading opening 607 mm
Spreading force at base of arm teeth
1
105 - 342 kN/
10.7 – 34.9 tons
Spreading force at base of jaw
67.6 – 173.2 kN/
6.9 – 17.7 tons
Spreading force 25 mm from tips
38.4 – 83.2 kN/
3.9 – 8.5 tons
NFPA HSF 76.7 kN / 7.8 tons
NFPA LSF 34.7 kN / 3.5 tons
Max. pulling opening 426 mm
Pulling force
45.9 – 91.2 kN/
4.7- 9.3 tons
NFPA HPF 59.6 kN / 6.1 tons
NFPA LPF 27.4 kN / 2.8 tons
Squeezing force at base of arm teeth
1
66.3 – 120.9 kN/
6.7 – 12.3 tons
EN 13204 AS38.4-607-15.0
NFPA 1936 Compliant
