USER MANUAL SPREADER X-SERIES
18
RESQTEC Manual SPREADER X-series (DM064K08)
1
Maximum is a theoretical force that cannot be measured
SPREADER X4
NEO1-COUPLER STD-COUPLER
Nominal pressure 350 bar
Tailhose safety factor - 8:1 (2,800 bar)
Dimensions (L x W x H) 826 x 350 x 312 mm
Operational weight 21.2 kg 22.5 kg
Max. spreading opening 687 mm
Spreading force at base of arm teeth
1
102.7 – 3,474.0 kN /
10.5 - 354.2 ton
Spreading force at base of jaw
71.8 - 213.6 kN /
7.3 - 21.8 ton
Spreading force 25 mm from tips
53.0 - 91.0 kN /
5.4 - 9.3 ton
NFPA HSF 82.3 kN / 8.4 ton
NFPA LSF 49.4 kN / 5.0 ton
Max. pulling opening 532 mm
Pulling force
63.4 - 128.1 kN /
6.5 - 13.1 ton
NFPA HPF 74.9 kN / 7.6 ton
NFPA LPF 45.8 kN / 4.7 ton
Squeezing force at base of arm teeth
1
176.7 - 289.0 kN /
18.0 - 29.5 ton
EN 13204 AS53-687-21.2
NFPA 1936 Compliant
