USER MANUAL SPREADER X-SERIES
RESQTEC Manual SPREADER X-series (DM064K08)
1
Maximum is a theoretical force that cannot be measured
SPREADER X6
NEO1-COUPLER STD-COUPLER
Nominal pressure 350 bar
Tailhose safety factor - 8:1 (2,800 bar)
Dimensions (L x W x H) 915 x 350 x 312 mm
Operational weight 25.5 kg 26.7 kg
Max. spreading opening 802 mm
Spreading force at base of arm teeth
1
109.0 – 2,273.8 kN /
11.1 - 231.9 ton
Spreading force at base of jaw
77.7 - 172.0 kN /
7.9 - 17.5 ton
Spreading force 25 mm from tips
60.4 - 87.4 kN /
6.2 - 8.9 ton
NFPA HSF 80.9 kN / 8.3 ton
NFPA LSF 57.0 kN / 5.8 ton
Max. pulling opening 633 mm
Pulling force
69.3 - 110.6 kN /
7.1 - 11.3 ton
NFPA HPF 74.2 kN / 7.6 ton
NFPA LPF 52.8 kN / 5.4 ton
Squeezing force at base of arm teeth
1
173.4 - 245.7 kN /
17.7 - 25.0 ton
EN 13204 BS60.4-802-25.5
NFPA 1936 Compliant
