RESQTEC X2 - Imperial System Specifications; Imperial System Data

USER MANUAL SPREADER X-SERIES
20
RESQTEC Manual SPREADER X-series (DM064K08)
5.1.2 IMPERIAL SYSTEM DATA
1
Maximum is a theoretical force that cannot be measured
SPREADER X2
NEO1-COUPLER STD-COUPLER
Nominal pressure 5,075 PSI
Tailhose safety factor - 8:1 (40,600 PSI)
Dimensions (L x W x H) 28 3/4’’ x 12 1/8’’ x 10 1/2’’
Operational weight 33.1 lbs 35.5 lbs
Max. spreading opening 23 7/8’’
Spreading force at base of arm teeth
1
23,605 – 76,885 lbs /
11.8 - 38.4 US ton
Spreading force at base of jaw
15,197 – 38,937 lbs /
7.6 - 19.5 US ton
Spreading force 1" from from tips
8,633 – 18,704 lbs /
4.9 - 8.4 US ton
NFPA HSF 17,243 lbs / 8.6 US ton
NFPA LSF 7,801 lbs / 3.9 US ton
Max. pulling opening 16 3/4’’
Pulling force
10,319 – 20,503 lbs /
5.2 - 10.3 US ton
NFPA HPF 13,399 lbs / 6.7 US ton
NFPA LPF 6,160 lbs / 3.1 US ton
Squeezing force at base of arm teeth
1
14,905 – 27,179 lbs /
7.5 - 13.6 US ton
EN 13204 AS38.4-607-15.0
NFPA 1936 Compliant
