USER MANUAL SPREADER X-SERIES
RESQTEC Manual SPREADER X-series (DM064K08)
1
Maximum is a theoretical force that cannot be measured
SPREADER X4
NEO1-COUPLER STD-COUPLER
Nominal pressure 5,075 PSI
Tailhose safety factor - 8:1 (40.600 PSI)
Dimensions (L x W x H) 32 1/2’’ x 13 3/4’’ x 12 1/4’’
Operational weight 46.7 lbs 49.6 lbs
Max. spreading opening 27’’
Spreading force at base of arm teeth
1
23,088 – 780,986 lbs /
11.5 - 390.5 US ton
Spreading force at base of jaw
16,141 – 48,019 lbs /
8.1 - 24.0 US ton
Spreading force 1" from from tips
11,915 - 20,458 lbs /
6.0 - 10.2 US ton
NFPA HSF 18,519 lbs / 9.3 US ton
NFPA LSF 11,106 lbs / 5.6 US ton
Max. pulling opening 21’’
Pulling force
14,253 – 28,798 lbs /
7.1 - 14.4 US ton
NFPA HPF 16,838 lbs / 8.4 US ton
NFPA LPF 10,296 lbs / 5.1 US ton
Squeezing force at base of arm teeth
1
39,724 – 64,970 lbs /
19.9 - 32.5 US ton
EN 13204 AS53-687-21.2
NFPA 1936 Compliant
