USER MANUAL SPREADER X-SERIES
22
RESQTEC Manual SPREADER X-series (DM064K08)
1
Maximum is a theoretical force that cannot be measured
SPREADER X6
NEO1-COUPLER STD-COUPLER
Nominal pressure 5,075 PSI
Tailhose safety factor - 8:1 (40,600 PSI)
Dimensions (L x W x H) 36’’ x 13 3/4’’ x 12 1/4’’
Operational weight 56.2 lbs 58.9 lbs
Max. spreading opening 31 5/8’’
Spreading force at base of arm teeth
1
24,504 – 511,171 lbs /
12.3 - 255.6 US ton
Spreading force at base of jaw
17,468 – 38,667 lbs /
8.7 - 19.3 US ton
Spreading force 1" from from tips
13,579 – 17,625 lbs /
6.8 - 9.8 US ton
NFPA HSF 18,187 lbs / 9.1 US ton
NFPA LSF 12,814 lbs / 6.4 US ton
Max. pulling opening 24 7/8’’
Pulling force
15,579 – 24,864 lbs /
7.8 - 12.4 US ton
NFPA HPF 16,681 lbs / 8.3 US ton
NFPA LPF 11,870 lbs / 5.9 US ton
Squeezing force at base of arm teeth
1
38,982 – 55,236 lbs /
19.5 - 27.6 US ton
EN 13204 BS60.4-802-25.5
NFPA 1936 Compliant
