USER MANUAL SPREADER X-SERIES
10
RESQTEC Manual SPREADER X-series (DM064K08)
4.5. QUICK ACTION COUPLERS
The standard product is equipped with NEO1 quick action automatic by-pass couplers. This makes it possible to connect and disconnect both
pressure

and
return
in

one
simple
motion.

It

also

allows

you

to

connect

and
disconnect

under

full
pump

free

ow

pressure.
If

your

product

is
supplied with STD connectors, the connectors for pressure and return are separated. Make sure the pump is switched to neutral when
connecting

or

disconnecting

these

STD

connectors.

If

your

product

is
modied
on

your

request

with
other

couplers,

please

also

refer

to

that

coupler supplier’s manual for proper additional instruction.
BEFORE USAGE, MAKE SURE TO CHECK THE FOLLOWING:
4.6. CONNECTING THE RESQTEC NEO1 COUPLER
• Make sure connectors (and pins) are clean to ensure proper operation.
• Pull both couplers to check whether the couplers are properly connected.
• If couplers do not have auto lock mechanism on the product, rotate collar of female coupler to lock and prevent accidental release.
• Unroll hose reels to their full extend. Make sure that no pressure is applied before unrolling.
Make sure the dust caps are removed from both the couplers (male & female):
• Female dust cap releases when female coupler is released (rotate and pull back).
• Male dust cap releases by simply pulling it.
1
Align the NEO1 female coupler located on the hose with the NEO1 male coupler
located on the product.
2
Pushtoconnectinoneswiftmotion(ifdifculttoconnectrefertochapter4.10for
pressure release).
3
