Assembling and using the cyclone
35
Fig. 25: Assembled cyclone
CAUTION
Before using the industrial vacuum cleaning, read the operating instructions supplied with the
vacuum cleaner.
Fig. 26: Connecting the industrial vacuum cleaner
• Plug the connector for dust extraction (W1) into the top opening on the
cyclone.
W1
W1
