3 Ratings and Dimensions
Description Symbol Unit DKC03.3-040 DKC03.3-100 DKC03.3-200
listing according UL-standard (UL) UL 508 C
listing according CSA-standard (UL) Canadian National Standard(s) C22.2 No. 14-05
UL files (UL) E134201 E134201 E134201
pollution degree (UL) Use in a pollution degree 2 environment
maximum ambient temperature with nominal
data (UL)
T
amax
°C 45 45 45
maximum ambient temperature with reduced
nominal data (UL)
T
amax_red
°C 55 55 55
Weight m kg 5,7 9,7 19,5
Device height (UL)
1)
H mm 360 360 360
Device depth (UL)
2)
T mm 261 261 261
Device width (UL)
3)
B mm 65 105 230
minimum distance on the top of the device
4)
d
top
mm 150 150 150
minimum distance on the bottom of the device
5)
d
bot
mm 80 80 80
rated control voltage input (UL)
6)
U
N3
V242424
rated power consumption control voltage input
without holding brake, without control section
at U
N3
= DC 24 V (UL)
7)
P
N3
W212629
short circuit current rating, SCCR,
symmetrical amperes (UL)
8)
I
SCCR
A rms 42000 42000 42000
rated input voltage, power (UL)
9)
V 200 … 480 200 … 480 200 … 480
tolerance rated input voltage (UL) % ±10 ±10 ±10
input number of phases (UL) 1 × AC, 3 × AC 1 × AC, 3 × AC 1 × AC, 3 × AC
input frequency (UL) f
LN
Hz 50 … 60 50 … 60 50 … 60
tolerance input frequency (UL) Hz 2 2 2
maximum input current (UL)
10)
I
L_cont
A164038
branch circuit protection fuse (UL)
11)
20 70 70
field wiring material (UL)
12)
Use 60/75 °C copper wire only, use class 1 wire
only or equivalent
required wire size according UL 508 A
(internal wiring); at I
L_cont
(UL)
13)
A
LN
AWG 12 AWG 8 AWG
maximum output voltage (UL) U
out
V 800 800 800
output number of phases (UL) 3 3 3
maximum output current (UL) I
out_max
A 40 100 200
maximum output frequency (UL) f
out
Hz 1000 1000 1000
