Rexroth EcoDrive 03 DKC**.3-040...200 Instructions for Use 5-17
DOK-ECODR3-DKC40*200UL-IB01-EN-P
min. tightening torque
[Nm]
max. tightening torque
[Nm]
2.5 3.0
Fig. 5-39: Tightening torque
Cross section
single wire
[mm²]
Max. connectable
cross section
in mm²
Max. cross section
in AWG
gauge no.:
-- 25 --
Allocation
Motor
Mains
XS1, XS2, XS3 Shield Connections
XS1
Connection for shield:
• Total motor cable shield
• Holding brake
• Motor temperature monitoring
• Mains supply
XS2
Connection for shields of cables at X1, X3 and those for the command
communication interfaces.
XS3
Connection for shields of cables at X9, X10 and X11.
Drive controller XS1 XS2 XS3
DKC**.3-040 12-18 6-15 6-15
DKC**.3-100 12-35 6-15 6-15
DKC**.3-200 19-35 6-15 6-15
Fig. 5-40: Allowed outside diameters in mm
Note: Always connect the shield connections of the cables
(especially of the motor cables) with a large contact surface.
Tightening torque:
Connection cross section:
XE1
XE2
Allowed outside diameters:
