Rexroth EcoDrive 03 DKC**.3-040...200 Identification 2-1
DOK-ECODR3-DKC40*200UL-IB01-EN-P
2 Identification
2.1 Type Code
Note: The following figure illustrates the basic structure of the type
code. Our sales representative will help you with the current
status of available versions.
DKC 03.3 - 040 - 7 - FW
DKC
TL0001F1.FH7
Drive controller
Type code fields:
Example:
3
7
FW
Voltage category
Firmware
Version
A firmware specifying the functions of the
drive must be ordered separately.
xx
Series
Type current
40 A
100 A
040
100
200
200 A
16 A
016
Fig. 2-1: Type code
2.2 Type Plates
Basic Unit
TS0012F1.FH7
Serial number
Hardware index
Barcode
Fig. 2-2: Type plate
Unit type
TS0014F1.FH7
Production week
Serial number
Hardware index
Barcode
Part number
Device type
Fig. 2-3: Type plate – DKC example
