M1 User Manual

(2) User can adjust the position, size for the selected layer, and set DSK, BLEND and MASK, some

function coming soon.

3.4.5 Scale and Crop the Layer

(1) Push any button of [A] to [B] in Layer Selection Area, the light is red lit when the layer is

selected.

(2) Push the [SCALE] button in Layer Adjustment Area or on the LCD screen, and enter

the scale menu as follows:

Use the rotary knob to adjust the scale of the layer.

H Pos: Set horizontal position.

V Pos: Set vertical position.

H Size: Set horizontal size.

V Size: Set vertical size.

Reset: If improper operation occurs, it can be restored by reset

(3) Push the [SCALE] button in Layer Adjustment Area or on the LCD screen, and enter

the scale menu as follows:

Use the rotary knob to adjust the crop of the layer.

Crop H Pos: Crop the horizontal position.

Crop V Pos: Crop the vertical position.

Crop H Size: Crop the horizontal size.

Crop V Size: Crop the vertical size.

Reset: Reset crop if image quality i distorted by improper operation.

3.4.6 DSK Setting

(1) Firstly, enable the 2 layers function.

-> H Pos 465

V Pos 1248

H Size 956

V Size 540

Reset >>

-> Crop H Pos 0

Crop V Pos 0

Crop H Size 1920

Crop V Size 1080

Reset >>
