RGBlink M1 User Manual

M1 User Manual
33
DSK On
Preset Black Background
Mode Key In
Alpha 128
Red Min 0
Red Max 15
Green Min 0
Green Max 15
Blue Min 0
Blue Max 15
(2) Push [MENU] button, and enter to the menu items. Turn the rotary knob, and select <DSK>
option in LCD screen, rotary the knob or touch the <DSK> to confirm.
DSK: Can select enable or disable the DSK function.
Preset: Users can select black background, white background, red background, green background
and blue background.
Mode: Select Key In or Key Out.
Alpha: The adjustment range is between 0~128.
Red Min: The adjustment range is between 0~255.
Red max: The adjustment range is between 0~255.
Green Min: The adjustment range is between 0~255.
Green Max: The adjustment range is between 0~255.
Blue Min: The adjustment range is between 0~255.
Blue Max: The adjustment range is between 0~255.
3.4.6.1 Key In and Key Out
(1) Key In
To cut out the color selected in [Preset] and other colors remain unchanged. Take Black
Background and Blue Background for example, see the effect below:
