RGBlink M1 User Manual

M1 User Manual
51
HDMI Input
Connector
Standard HDMI-A socket
Supported
Resolution
SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50/59.94/60 | 1080i50/59.94/60,
720p50/59.94/60
VESA: 800×600@60 | 1024×768@60 | 1280×720@60 | 1280×800@60 |
1280×960@60 | 1280×1024@60 | 1400×1050@60 | 1600×1200@60 |
1920×1080@60 | 1920×1200@60
Signal Level
TMDS pwl, single pixel input, 165MHz bandwidth
Format Standard
HDMI 1.3
HDMI Loop Out
Connector
HDMI standard type A interface
Supported
Resolution
SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC,
1080P50/59.94/60 | 1080i50/59.94/60,
720p50/59.94/60
VESA: 800×600@60 | 1024×768@60 | 1280×720@60 | 1280×800@60 |
1280×960@60 | 1280×1024@60 | 1400×1050@60 | 1600×1200@60 |
1920×1080@60 | 1920×1200@60
Format Standard
HDMI 1.3
HDMI PGM Output
Connector
HDMI standard type A interface
Number of Inputs
1
Supported
Resolution
SMPTE: 625/25/50 PAL, 525/29.97/59.94 NTSC,
720p50/59.94/60 | 1080i50/59.94/60 | 1080P50/59.94/60
VESA: 800×600@60Hz | 1024×768@60/75/85Hz | 1152x864@75Hz |
1280x720@50/59.94/60Hz | 1280×768@60Hz | 1280x800@60Hz |
1280x960@60/85Hz |
1280×1024@60/75/85Hz | 1366x768@20/60Hz | 1440x900@60Hz |
1400x1050@60Hz | 1600×1200@60Hz | 1920
×
1080@40/50/59.94/60Hz
| 1920
×
1080@50i/59.94i/60i
Format Standard
HDMI 1.3
SDI PGM Output
Connector
Standard BNC Socket
Number of Inputs
1
Data Rate
2.97Gb/s, 2.97/1.001Gb/s, 1.485Gb/s, 1.485/1.001Gb/s and 270Mb/s
Supported
Resolution
SMPTE 425M (3G Level A) 4:2:2: 1920×1080@60Hz (1:1) |
1920×1080@50Hz (1:1).
SMPTE 425M (3G Level B DS1 and DS2) 4:2:2: 1920×1080@60Hz (2:1) |
1920×1080@50Hz (2:1)
SMPTE 296M (HD): 1280×720@50Hz (1:1) | 1280×720@50Hz (1:1)
SMPTE 125M (SD): 1440×487@60Hz (2:1) | 525-line 487 generic
SMPTE ITU-R BT.656 (SD): 1440×576@50Hz (2:1),
625-line generic.
