(1) you can quickly return to the main menu by swiping from bottom to top (same as the【M】
key);
(2) back to last menu by swiping from left to right;
(3) enter the preset Load menu by swiping from top to bottom(same as the【S】key);
(4) enter more settings of current function by swiping from right to left.
When entering an operation item, such as adjusting the transition time, you can adjust it by
sliding the time bar on the screen, or by pushing the up and down keys on the left of the operation
board.
Preset Menu
In the preset menu (by pressing the【S】button or swiping from the top to the bottom of the
screen), the icons on the LCD screen default to the dark off state. Tap the icon to turn to the bright
color to get it selected and open preset (View), Chroma Key switch, Black switch , Record switch,
Mute switch, volume adjustment switch, etc.
The function of the icon button in the shortcut menu can be customized according to user’s needs.
3.2 Switch Source
The buttons ①②③④ on the operation board corresponds to the 4 HDMI inputs one-to-one.
When four signal source plug in, the lights on the signal source buttons will appear in four
states:
Steady green: The signal is recognized and no operation is performed;
Flashing green: The currently selected signal is ready to be switched;
Steady red: The current signal is in PGM output;
Unlit: No signal source is connected or the resolution of the signal source connected is not
accepted.
Switch Effect Setting
mini-pro is default 0.5S Fast Fade mode, by pushing ①②③④ signal buttons, 4 input signals
