26
11. Couple the applicator to the treatment area
by keeping the entire surface of the applicator
in contact with the gel that has been applied
to the patient. Move applicator in a slow but
continuous circular motion. This will ensure an
ecient delivery of therapeutic ultrasound to
the patient. Green LED on either side of the
applicator will light when coupling is achieved.
12. Adjust the intensity and start ultrasound
treatment that you are using by rotating the
ultrasound output intensity adjustable knob
on the control panel. Press the knob to change
the ultrasound unit “W” or “W / cm”.
13. Adjust the output intensity of the CH2 to
start electrical treatment that you are using by
rotating the output intensity adjustable knob
on the control panel to the patient’s comfort
level.
14. For safety using, load detection was
designed in this device after the stimulation
output intensity surpass 10.0V or the ultrasound
intensity over 0.5W. If there are no electrodes
stuck on patient’ skin or the applicator is
inadequate coupling to the patient, an alarm
buzzer sound will appear, the stimulation
intensity value and [
] symbol will flash.
15. Press the [STOP] button to stop treatment
if any emergency or error occurs.
CAUTION:
1. For device protection, a temperature
detection feature was designed to stop
electrical stim when temps reach over 160°F.
The device will not work again unless the
temperature reaches 140°F.
2. To protect the patient, the device will stop
ultrasound intensity output and the LED
on the applicator will flash if the applicator
temperature over 107°F. It will resume again
when the temperature below 105°F.
STOP
