Richmar ComboCare - Page 55

55
8.3.2 Interferential Traditional (2 Pole)
8.3.3 TENS and EMS Mode
Waveform Type Bi-phasic square
Mode Selection CC (Constant Current) or
CV (Constant Voltage)
Carrier Frequency (C.F.) 2.5kHz
Sweep High Beat Frequency (Beat H.) (Beat L.) - 150 Hz
Sweep Low Beat Frequency (Beat L.) 1-(Beat H.) Hz
Output Intensity 0-100mA (CC, at 1k ohm lead)
0-100 V (CV, at 1k ohm load)
Treatment time 1-60 minutes
Cycle time (cycle) Continuous, 5/5, 4/12, 10/10, 10/20, 10/30,
10/50
Ramp time (Ramp) 2 seconds
Waveform Type Mono- or Bi-phasic square
Mode Selection CC (Constant Current) or
CV (Constant Voltage)
Frequency 1-250 Hz
Frequency Modulation (F.M.) 0-249Hz
Burst rate (Burst) 0-10Hz (7 pulse)
Phase duration (P. Dur.) 30-400 μs
Amplitude Modulation (A.M.) 0%-100%
Output Intensity 0-100mA (CC, at 1k ohm lead)
0-100 V (CV, at 1k ohm load)
Treatment time 1-60 minutes
Cycle time (cycle) Continuous, 4/4, 4/8, 7/7, 5/5, 4/12, 10/10,
10/20, 10/30, 10/50
Ramp time (Ramp) 1 second
