9
T
ROUBLESHOOTING
9.7
4
Pull the paper straight up and out.
5
Insert Tray 1 into the machine until it snaps into place.
6
Open and close the front door to resume printing.
In the Fuser Area or Around the Toner
Cartridge
W
ARNING
: The fuser area is hot. Take care not to burn your
fingers when removing paper from the machine.
1
Open the front door and pull the toner cartridge out, lightly
pushing it down.
