Ricoh Aficio MP C3300 Function Guide

Custom size original to be scanned
BAO013S
Scan settings on the custom size setting screen
BAP042S
1. Original Size (X1 and Y1)
Specify the length and width of the original.
Enter the actual width and length in [X1] and [Y1], respectively, and then press the [ ] key.
2. Start Position (X2 and Y2)
Set Start Position to 0 mm (0 inch).
Enter "0" in both [X2] and [Y2], and then press the [ ] key.
3. Scan Area (X3 and Y3)
Specify the same values as Original Size (X1, Y1).
Enter the same values in [X3] and [Y3] as Original Size (X1 and Y1 respectively), and then press the [ ] key.
• For X1 and Y1, you can specify 140 mm (5.5 inches) or larger.
• To scan an original that is smaller than 140 mm (5.5 inches), configure the settings as though you
were scanning part of an original that is larger than 140 mm (5.5 inches). For example: to scan a CD
label on the exposure glass, specify X1
X3 and Y1 Y3 based on the chart below. For details about
scanning procedures, see "Setting procedure of a custom size when scanning part of an original".
Scan Settings
151
8

Ricoh Aficio MP C3300 Specifications

General

Print Technology	Laser
Print Speed (Black)	33 ppm
Print Speed (Color)	33 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Technology	CCD
Copy Speed	33 cpm
Max Paper Size	A3
Monthly Duty Cycle	150, 000 pages
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Scan Speed (B&W)	50 ipm
Scan Speed (Color)	50 ipm
Paper Output Capacity (Maximum)	500 sheets
Processor	600 MHz
Memory (Standard)	1 GB
Memory (Maximum)	1.5 GB
Power Consumption (Maximum)	1.5 kW
Functions	Print, Copy, Scan
Zoom	25% - 400%
Scan Destinations	Email, Folder, USB
Paper Weight	60 - 220 gsm
Hard Disk Drive	80 GB
Interface	USB 2.0, Ethernet
PDL (Page Description Language)	PCL6, PostScript 3
Operating Systems Compatibility	Windows, Mac, Linux
Power Source	220 - 240 V
