Ricoh Aficio MP C3300 Function Guide

Every Web Image Monitor page is divided into the following areas:
BHJ300S
1. Menu area
If you select menu, it's content will be shown on the work area, or the sub area.
2. Tab area
Details about each menu appears.
3. Header area
The dialog box for switching to the user mode and administrator mode appears, and each mode's menu will be
displayed.
The link to help and dialog box for keyword search appears.
4. Help
Use Help to view or download Help file contents.
5. Display area
Displays the contents of the item selected in the menu area.
Machine information in the display area is not automatically updated. Click [Refresh] at the upper right in the
display area to update the machine information. Click the Web browser's [Refresh] button to refresh the entire
browser screen.
• When using a host name under Windows Server 2003/2003 R2 or Windows Vista with IPv6 protocol,
perform host name resolution using an external DNS server. The host file cannot be used.
When User Authentication is Set
Login (using Web Image Monitor)
Follow the procedure below to log on when user authentication is set.
1. Click [Login].
Using Web Image Monitor
127
4

Ricoh Aficio MP C3300 Specifications

General

Print Technology	Laser
Print Speed (Black)	33 ppm
Print Speed (Color)	33 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Technology	CCD
Copy Speed	33 cpm
Max Paper Size	A3
Monthly Duty Cycle	150, 000 pages
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Scan Speed (B&W)	50 ipm
Scan Speed (Color)	50 ipm
Paper Output Capacity (Maximum)	500 sheets
Processor	600 MHz
Memory (Standard)	1 GB
Memory (Maximum)	1.5 GB
Power Consumption (Maximum)	1.5 kW
Functions	Print, Copy, Scan
Zoom	25% - 400%
Scan Destinations	Email, Folder, USB
Paper Weight	60 - 220 gsm
Hard Disk Drive	80 GB
Interface	USB 2.0, Ethernet
PDL (Page Description Language)	PCL6, PostScript 3
Operating Systems Compatibility	Windows, Mac, Linux
Power Source	220 - 240 V
