Ricoh Aficio MP C3300 Function Guide

Category Settings Setting Value
If you select [Active], select
Lockout Release Time of at least
60 minutes.
Security / User Lockout Policy Lock Out User for If you select [Lockout Release
Timer] select Lockout Release
Time of at least 60 minutes.
Settings when IPsec is available / unavailable
IPsec encrypts all network transmissions. If IPsec is available on your network, we recommend you enable
it to enhance the security of the data travelling on your network.
Settings when IPsec is available
If IPsec is available on your network, use the settings shown in the following table to enhance the security
of the machine's data when it is travelling on your network.
• Control Panel settings to configure when IPsec is available
Feature Setting Menu Tab Settings Setting Value
System Settings Interface
Settings
IPsec Active
System Settings Interface
Settings
Permit SSL/TLS
Communication *1
Ciphertext Only
*1
You can configure "Permit SSL/TLS Communication" using Web Image Monitor.
• Web Image Monitor settings to configure when IPsec is available
Category Settings Setting Value
Security / IPsec Exclude HTTPS
Communication
Set to [Active] or [Inactive].
Security / SSL/TLS Permit SSL/TLS
Communication *1
If you select [Active] for "Exclude HTTPS
Communication" set "Permit SSL/TLS
Communication" to [Ciphertext Priority].
Security / IPsec Encryption Key
Manual Settings
Active
Additional Information Enhanced Security
223
8

Ricoh Aficio MP C3300 Specifications

General

Print Technology	Laser
Print Speed (Black)	33 ppm
Print Speed (Color)	33 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Technology	CCD
Copy Speed	33 cpm
Max Paper Size	A3
Monthly Duty Cycle	150, 000 pages
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Scan Speed (B&W)	50 ipm
Scan Speed (Color)	50 ipm
Paper Output Capacity (Maximum)	500 sheets
Processor	600 MHz
Memory (Standard)	1 GB
Memory (Maximum)	1.5 GB
Power Consumption (Maximum)	1.5 kW
Functions	Print, Copy, Scan
Zoom	25% - 400%
Scan Destinations	Email, Folder, USB
Paper Weight	60 - 220 gsm
Hard Disk Drive	80 GB
Interface	USB 2.0, Ethernet
PDL (Page Description Language)	PCL6, PostScript 3
Operating Systems Compatibility	Windows, Mac, Linux
Power Source	220 - 240 V
