When Paper is Jammed
127
9
When “Remove Misfeed Internal Path” Appears
“Remove Misfeed Internal Path” appears when a paper jam has occurred in
the fusing unit.
Open the front cover and remove the paper.
Important
❒
Since the surrounding temperature is high around the guide, check for jammed
paper when it gets a little cooler.
A
Pull Front Cover Open Lever, and then open the front cover with both hands
carefully.
B Lower the blue fusing unit levers, and pull out the jammed paper carefully.
ASI025S
ASI052S
ASI053S
To Next Page
