3. Connecting the Printer
Network Connection
Follow the procedure below to connect the printer to the computer through the
network. Prepare a hub, straight-through Ethernet cable, and any other neces-
sary network devices before connecting the 10BASE-T or 100BASE-TX cable to
the printer's Ethernet port.
CAUTION:
Important
❒ Use shielded Ethernet cable. Unshielded cables create electromagnetic inter-
ference that could cause malfunctions.
❒ The Ethernet cable is not supplied with this printer. Select your cable accord-
ing to the network environment.
A Remove the cable cover.
B Connect the Ethernet cable to the Ethernet port.
• Do not connect the Ethernet port of the machine to a network that may sup-
ply excess voltage, such as a telephone line. Doing so may result in fire or
electric shock.
ASI081S
ASH052S
