Installing the Printer and Options
16
2
B Turn off the printer's power switch, and then unplug the printer's power
cord from the wall outlet.
C Remove the adhesive tape from the optional paper feed unit.
D Lift the printer using the inset grips on both sides of the printer.
E There are three upright pins on the optional paper feed unit. Align them
with the holes on the underside of the printer, and then carefully lower the
printer.
ASH025S
ASI004S
ASI064S
To Next Page
