Catalog Explorer User Manual
______________________________________________________________________________
________________________________________________________________________________
Page 5 of 36
Visit our knowledgebase at: http://www.ricoh-usa.com/support/knowledgebase.asp
Copyright 2008 Ricoh Americas Corporation
1. What is the Catalog Explorer?
Using actual data from the Parts Catalog, this 3D viewing tool displays images of the
units/sections and individual parts used on a particular model. This tool is particularly useful
in that it allows the user to search for a specific part used on that model by specifying a
unit/section of the machine, and then performing a search to narrow down the results. Search
methods include entering a keyword (e.g. part name, part number), selecting a keyword from
a pull-down menu (e.g. type of part, physical section of the unit selected), specifying a
physical area of the mainframe with the mouse, and other methods.
