Rear
CPL002
1
3
2
4
1. Original exit
Originals are delivered here.
2. Ventilation holes
Prevent overheating.
3. Ink collector unit cover
Open this cover to replace the ink collector unit. Ink used for maintenance collects in the ink collector unit.
4. Original output guide
Stacks originals delivered to the rear output.
