Combining Multiple Pages
This section describes how to set the machine to combine multiple pages (2 or 4 pages) of an original
onto a single page.
To use this function, the paper size used for printing copies must be set to A4 or Letter.
2 on 1
You can copy two pages of an original onto a single sheet of photocopied paper. Depending on
the orientation of the original, the printout format can be selected from the following:
Portrait
CES033
Landscape
CES034
4 on 1
You can copy four pages of an original onto a single sheet of photocopied paper. Depending on
the orientation of the original, the printout format can be selected from the following:
Portrait: L to R
CES035
Portrait: T to B
4. Copying Originals
60
