5010e_513.doc / 22.01.10
OPERATING ELEMENTS
3 OPERATING ELEMENTS
3.1 FRONT
working area
printer cover
lid
aspiration tube
touchscreen
sipping lever [P]
3.2 BACK
ROBERT RIELE GmbH & Co KG Page 10 3 -
