7.2.18 ADC counts (Optic) 7.2.18 ADC counts (Optic)
Indicated is the current value of the optical
analogue-digital converter. The value is
proportional to the light-current depending on
the selected amplification level and the boost
setting.
To a key actuation the system reacts possibly
nly after three seconds.
The functions V0 to V7 set the amplification
level. The function BO increases (boost ON)
or reduces (boost OFF) the time slot. The
functions F0 to F9 place the filter wheel into
the positions 0 to 9. The position 0 corre-
sponds to the filter wheel position at the dark
adjustment.
o
UTILITIES PAGE 5/5
ADC COUNTS (OPTIC)
BOOST OFF
V0 F1 340 nm 21336
V0 V1 V2 V3 V4 V5 V6 V7 BO.
F0 F1 F2 F3 F4 F5 F6 F7 F8 F9
ESC
Stop function by [ESC].
7.2.19 Send results
Start sending stored results through the serial
port by pressing [START] or cancel with
[EXIT].
After sending is completed you will be
prompted to delete stored results. Press
[START] to delete results or [EXIT] to exit
without deleting results.
SEND RESULTS
EXIT START
7.2.20 Service tools
The service tools are reserved for trained
specialists only and therefore protected by a
password.
Stop function by [ESC].
SERVICE TOOLS
PASSWORD
1 2 3 4 5 6 7 8
ESC 9 0 . + - E
