Riele 5010 V5+ - Error List; Key Signal on; off; Touchscreen Adjustment

5010e_513.doc / 22.01.10
7.2.13 Error list 7.2.13 Error list
The last 10 serious errors are shown or
printed.
The oldest error is shown first. The last error is
always marked with no 1.
By [NEXT] earlier error messages are shown.
By [PRINT] the complete error list is printed or
output to the serial interface.
For troubleshooting the coded error list can be
consulted (chapter 9.4 - CODED ERROR
MESSAGES).
ERROR LIST
NO. 1
DATE 09/08/09
ERROR CODE 46
EXIT PRINT NEXT
7.2.14 Key signal ON / OFF
The current status of the key signal is indi-
cated in the first line by OFF or ON.
Change setting by [SELECT].
Save setting permanently by [OK].
Save setting temporarily up to next switch-off
of the device by [EXIT].
The deeper signal tone for error messages
remains active in any case.
KEY SIGNAL ON
EXIT OK SELECT
7.2.15 Touchscreen adjustment
By this function the panel can be adjusted.
After call of the function a white cross is
shown in the left lower corner of the screen.
Touch the intersection point in the cross with a
non-scratching plastic tip (touchscreen pen,
pipette tip) as exactly as possible. In the first
line the coordinates are shown as X- and Y-
value. The input will be accepted and the
coordinate display will be reset after a time out
of 10s. Then the cross is shown in the right
upper corner. Touch the intersection point.
After a timeout of 10s the memory inquiry
follows.
Save the adjustment by [OK].
Reject the adjustment by [EXIT].
X 0 Y 0
TOUCH PANEL ADJUSTMENT
PRESS EXACTLY THE CROSSPOINT
TIME 10
SAVE TP ADJUSTMENT
EXIT OK
ROBERT RIELE GmbH & Co KG Page 59 7- UTILITY PROGRAMS Y PROGRAMS
