>9.2 EXTERNAL SYNCHRONISATION
This non-insulated input can be used to synchronise Inverter output with a suitable signal from an external source.
It is essential when the MULTI SENTRY is used in combination with Static Switch Transfer Systems.
At installation, it is important to:
use an insulation transformer with insulated single-phase output (SELV), 12÷24 Vac and power ≥ 0,5 VA
(available if required);
connect the transformer secondary to the "EXTERNAL SYNC" terminal through a double-insulation cable
with cross-sectional area of 1 sq.mm.
The external synchronisation must be enabled through the advanced configuration software ("UComGP")
assigned to authorized personnel.
>9.3 MONITORING AND CONTROL SOFTWARE
The UPS is supplied with Powershield³ UPS monitoring and control software to provide the following:
Chronological event recording
UPS operating status management
E-mail, modem, SNMP agent support
Sequential shutdown and load-shedding within a network environment
