14. TECHNICAL DATA 10÷20 kVA Single-Phase
Mechanical characteristics
UPS Power Modules (kVA)
10
12
15
20
Dimensions (mm)
 Width MCM/MSM
 Depth MCM/MSM
 High MCM/MSM
320/440
840/850
930/1320
Max. Weight with internal batteries (kg)
MCM
MSM
185 kg
315 kg
187 kg
320 kg
195 kg
325 kg
200 kg
330 kg
Ventilation
Forced through internal fans
Cabinet IP rating
IP20
Cable input
From the bottom/On the rear
Colour
RAL 7016
Electrical Specifications
UPS Power Modules (kVA)
10
12
15
20
INPUT
Nominal voltage
380-400-415 Vac Three-phase with neutral or
220-230-240 Vac Single-phase
Current input voltage three-phase
(1)
Current input voltage monophase
(1)
20
60
23
71
28
84
37
109
Voltage range (without switching to
battery power)
320÷480 @ 100% of the load 240÷480 V @ 50% of the load (3 Ph)
184÷276 @ 100% of the load 140÷276 V @ 50% of the load (1 Ph)
Nominal frequency
50 or 60 Hz
Input frequency tolerance
From 40 to 72 Hz
Total Harmonic distortion (THDi) and
power factor with full load and source
THDv <1%
THDi 3 % ; 0,99 pf
Rectifier progressive start-up
(Power Walk-in duration)
Programmable from 1 to 125 sec. in steps of 1 sec.
(standard disable)
Adjustable delay for the rectifier start up
(Power Walk-in start delay)
Programmable from 1 to 120 sec. in steps of 1 sec.
(standard function is at 3 sec.)
(1)
The input current is stated for the following conditions:
 Output load at 0,9 pf
 Input voltage at 346 Volt (three-phase) / 200 Volt (monophase)
 Battery charging current of 4 Ampere
