59
• Take care that the shifting arm point front
up. Insert the rear wheel into the dropouts.
Take care of correct position of the chain on
chainwheel and sprocket.
• Insert the rear wheel into the dropouts.
Take care of correct position of the chain on
chainwheel and sprocket.
POSITION OF THE WHEEL AND
CHAIN TENSION
• Check that the wheel is centered and if the
chain tension is sucient. More details on
the chain tension can be found on page
44 – 45.
• Make sure that the chain is correctly placed
on the front chainwheel. Please refer to
page 44 – 45.
TIGHTENING THE WHEEL ATTACHMENT
• Tighten the axle nuts or the quick release
to the specified torque settings (refer to
page 77).
• On bikes with coaster brakes, tighten
the brake arm attachment to a
torque of 4– 6 Nm.
CHECK BRAKE FUNCTION
• Hang the brake cable again.
• Check that the cable housing on rim or disc
brakes is still correctly positioned.
• After assembly check whether the brake
surfaces are free of grease and lubricants.
CHECK SHIFTING SYSTEM
Check the function of the shifting system.
ROHLOFF HUB
On bikes with a Rohlo hub, mount the shift
cables (see instructions in Rohlo manual).
NUVINCI UND NUVINCI HARMONYSYSTEM
Please observe the instructions of the
separately included NuVinci manual.
Incorrect installation can lead to
functional disruptions or failures
in the shifting or braking sys-
tems. After installing your wheel,
thoroughly check the shifting
and braking system!
DANGER!
