User’s Guide for DG1022
1-4
The Front/Rear Panel
When you get a new DG1022 Dual-Channel Function/Arbitrary Waveform Generator,
first you need to know how to operate the front/ Rear panel correctly. This chapter will
make a brief introduction and description for the operation and functions of the Front/
Rear Panel.
Front Panel at a Glance
DG1022 Generator has clear and simple front panel. The Front Panel has a knob,
functional keys and menu buttons. The 6 grey buttons below the screen are menu
buttons, by using which you can choose different options on the current menu. The
rests are the functional keys, with which you can enter different function menus or
obtain specific functional applications directly.
Figure 1-3
Front Panel for DG1022
Power Menu Keys CH1 Output CH1 Output
Button Connector
Display Mode Waveform Channel Keypad CH2 Output CH2 Output/
Switch Keys Switch Button Counter Input
Mode/ Direction
USB Host LCD Screen Functions Key Knob
