Rigol DG1012 - Characteristics

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DG10× 2 Series
5-2
Characteristics
Frequency (DG1022)
Waveforms
Sine, Square, Ramp, Triangle, Pulse, Noise, Arb
Sine
1µHz ~ 20MHz
Square
1µHz ~ 5MHz
Ramp, Triangle
1µHz ~ 150kHz
Pulse
500µHz ~ 3MHz
Noise
5MHz (-3dB)
Arb
1µHz ~ 5MHz
Resolution
1 µHz
Accuracy
± 50 ppm in 90 days
± 100 ppm in 1year
18°C ~ 28°C
Temperature index
< 5 ppm/°C
Frequency (DG1012)
Waveforms
Sine, Square, Ramp, Triangle, Pulse, Noise, Arb
Sine
1µHz ~ 15MHz
Square
1µHz ~ 4MHz
Ramp, Triangle
1µHz ~ 100kHz
Pulse
500µHz ~ 2MHz
Noise
5MHz (-3dB)
Arb
1µHz ~ 4MHz
Resolution
1 µHz
Accuracy
± 50 ppm in 90 days
± 100 ppm in 1year
18°C ~ 28°C
Temperature index
< 5 ppm/°C
Sine Wave Spectral Purity
Harmonic Distortion
CH1
CH2
≤1VPP
>1VPP
≤1VPP
>1VPP
