User’s Guide for DG1022
2-37
To Generate Burst Signal
Burst Function can generate versatile waveforms in burst, which can last specific
times of waveform cycle(N-Cycle Burst), or when the external gated signals (Gated
Burst) is applied, any waveform could be used, but noise can only be used in Gated
Burst.
Press the Burst button, in the Normal Mode, the operation menu will appear on the
screen, see Figure 2-44. Set the Waveform parameters by using the operation menu.
Figure 2-44
Burst Waveform Parameter Setting Interface

Rigol DG1012 Specifications

General

Output Channels	2
Sample Rate	100 MSa/s
Vertical Resolution	14 bits
Waveform Types	Sine, Square, Ramp, Pulse, Noise, DC
Output Impedance	50 Ω
Modulation Types	AM, FM, PM
Power Supply	100 - 240 V AC, 50/60 Hz
