Performance Verification Test
This chapter takes DHO1104 as an example to illustrate the performance verification
test methods and procedures of DHO1000 series digital oscilloscope. This manual
recommends the following test devices. You can also use other devices that fulfill the
"Specification" in
Table 5.1 Test Devices .
Table 5.1 Test Devices
Device Specification Recommended Model
Oscilloscope
Calibrator
3 mV to 4 V, ±0.1% accuracy Fluke 9500B
TIP
1. Make sure that the oscilloscope passes the self-test and the self-calibration is performed
before executing the performance verification tests.
2. Make sure that the oscilloscope has been warmed up for at least 30 minutes before
executing any of the following tests.
3. Please reset the instrument to the factory setting before or after executing any of the
following tests.
5.1 Random Noise Test
This test tests the random noise for each channel in the Normal acquisition mode.
5.1.1 Specification
Noise Floor,Typical (2 GSa/s Sample Rate, 1 Mpts Memory Depth, 20 μs Time
Base)
DHO1072/DHO1074 DHO1102/DHO1104 DHO1204/DHO1202
500 μV/div
62 μV
rms
66 μV
rms
75 μV
rms
1 mV/div
64 μV
rms
68 μV
rms
77 μV
rms
2 mV/div
68 μV
rms
76 μV
rms
77 μV
rms
5 mV/div
74 μV
rms
82 μV
rms
95 μV
rms
10 mV/div
76 μV
rms
87 μV
rms
101 μV
rms
20 mV/div
97 μV
rms
101 μV
rms
144 μV
rms
50 mV/div
134 μV
rms
162 μV
rms
305 μV
rms
100 mV/div
974 μV
rms
1.1 mV
rms
1.4 mV
rms
200 mV/div
1.2 mV
rms
1.3 mV
rms
1.8 mV
rms
500 mV/div
3.6 mV
rms
4.3 mV
rms
6 mV
rms
Performance Verification Test
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 Performance Verification
11
