Appendix: Test Record Form
RIGOL DHO1000 Series Digital Oscilloscope Performance Verification Test Record
Form
Model: ________________ Tested by: ________________ Test Date: ________________
Random Noise Test Record Form
Vertical
Scale
Bandwidth
Test
Result
Maximum
Pass/
Fail
DHO1072/
DHO1074
DHO1102/
DHO1104
DHO1204/
DHO1202
500 μV/div Full BW
62 μV
rms
66 μV
rms
75 μV
rms
1 mV/div Full BW
64 μV
rms
68 μV
rms
77 μV
rms
2 mV/div Full BW
68 μV
rms
76 μV
rms
77 μV
rms
5 mV/div Full BW
74 μV
rms
82 μV
rms
95 μV
rms
10 mV/div Full BW
76 μV
rms
87 μV
rms
101 μV
rms
20 mV/div Full BW
97 μV
rms
101 μV
rms
144 μV
rms
50 mV/div Full BW
134 μV
rms
162 μV
rms
305 μV
rms
100 mV/div Full BW
974 μV
rms
1.1 mV
rms
1.4 mV
rms
200 mV/div Full BW
1.2 mV
rms
1.3 mV
rms
1.8 mV
rms
500 mV/div Full BW
3.6 mV
rms
4.3 mV
rms
6 mV
rms
1 V/div Full BW
4.3 mV
rms
5 mV
rms
7.9 mV
rms
2 V/div Full BW
6 mV
rms
7 mV
rms
13 mV
rms
5 V/div Full BW
30 mV
rms
34.5 mV
rms
49 mV
rms
10 V/div Full BW
36 mV
rms
44 mV
rms
74 mV
rms
Impedance Test Record Form
Channel Vertical Scale Test Result Limit Pass/Fail
CH1
50 mV/div 0.99 MΩ to 1.01 MΩ
500 mV/div 0.99 MΩ to 1.01 MΩ
CH2
50 mV/div 0.99 MΩ to 1.01 MΩ
500 mV/div 0.99 MΩ to 1.01 MΩ
CH3
50 mV/div 0.99 MΩ to 1.01 MΩ
500 mV/div 0.99 MΩ to 1.01 MΩ
CH4
50 mV/div 0.99 MΩ to 1.01 MΩ
500 mV/div 0.99 MΩ to 1.01 MΩ
Appendix: Test Record Form
DHO1000 Performance Verification
28
