1 n2

Rising Edge Count = n

Threshold

Upp

r Limit

Threshold

Lower

Limit

Falling Edge Count

It is specified as the number of falling edges that fall from above the threshold

upper limit to below the threshold lower limit.

1 n2

Falling Edge Count = n

Threshold

Upper L

imi

Threshold

Lower

Limit

Measurements

DHO1000 User Guide

141
