Page #176 background imageLoading...
Page #176 background image
Select the Measurement Item
In the Measure item, you can select the desired measurement item. Available options
include Frequency, Period, and Totalize. Wherein, Totalize indicates the count of edge
events on the signal.
Clear Count
When "Totalize" is selected as the measurement item, the oscilloscope measures the
count of edge events on the signal. At this time, click or tap
Clear Count to clear the
measurement results and start the measurements again.
Statistics Results
When "Frequency" or "Period" is selected, click or tap the Statistic on/off switch to
turn on/off displaying all statistical items. When enabled, all the statistical results will
be displayed in the "Counter" label in the "Result" bar.
11.2.2 Reset Statistics
Click or tap the "Counter" label in the "Result" bar at the right section of the screen
and a window is displayed. Click or tap Reset Stat. in the window to reset the
statistics.
11.2.3 Remove the Measurement
Click or tap the "Counter" label in the "Result" bar at the right section of the screen
and a window is displayed. Click or tap Remove to clear the measurement results. The
"Counter" label disappears from the "Result" bar accordingly. You can also click or tap
Remove in the counter setting menu to disable the function.
Digital Voltmeter (DVM) and Frequency Counter
DHO900 User Guide
160
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
