Product Features

• Ultra-low noise floor, purer signal, never miss the small signals

• Up to 12 bits resolution for all the models of this series

• Max. analog bandwidth of 250 MHz, 4 analog channels

• 16 digital channels (std.), logic probe required to be purchased if needed

• Max. real-time sample rate of 1.25 GSa/s

• Max. memory depth of 50 Mpts

• Vertical sensitivity range: 200 μV/div to 10 V/div

• Max. capture rate of 1,000,000 wfms/s (in UltraAcquire mode)

• Digital phosphor display with real-time 256-level intensity grading

• Integrates the AFG function, bode plot analysis, histogram, digital signal

analysis, and etc

• Waveform search and navigation function allows you to debug the signal

anomalies faster

• 7" (1024x600) capacitive multi-touch screen

• Flex Knob brings user-friendly experience

• USB Device & Host, LAN, and HDMI interfaces (std.) for all the models of this

series

• Novel and delicate industrial design, easy to operate

• Unique online upgrade

The DHO900 series is RIGOL's high-performance economical digital oscilloscope.

Though compact in design, it has superior performance. It features a capture rate

up to 1,000,000 wfms/s (in UltraAcquire Mode), 50 Mpts memory depth, 12 bits

resolution, and low noise.

The DHO900 series supports 16 digital channels. One instrument can make an

analysis on both the analog and digital signals to meet the embedded design and

test scenarios. With an affordable price equivalent to purchasing an entry-level

instrument, you can access the auto serial and parallel bus analysis, bode plot

analysis, and other functions to meet the test demands in the R&D, education, and

scientific research fields.
