Select a Specified Digital Channel

Click or tap the ChanSelect drop-down button to select a digital channel. You can

select any channel from D0 to D15.

Use Preset Labels

Click or tap the Label library drop-down button to select a preset label. Available

preset labels include ACK, ADO, ADDR, BIT, CAS, CLK, CS, DATA, HALT, INT, LOAD,

NMI, OUT, RAS, PIN, RDY, RST, RX, TX, WR, MISO, MOSI, and D0-D15.

Input a Label Manually

Click or tap the Edit input field and use the pop-up virtual keypad to set the label. For

the methods of using the virtual keypad, refer to

Parameter Setting Method

Digital Channel

DHO900 User Guide

164
